SG5032CCN 晶振是EPSON/爱普生的一款额定频率2.5MHz ~ 50MHz的石英晶体振荡器，4脚贴片，5032封装常规有源晶振，具有小尺寸，高稳定性。该款有源晶体振荡器，可以在B : -20 °C to +70 °C / G : -40 °C to +85 °C的温度内稳定工作,它广泛应用于汽车多媒体、车身电子、遥控、太空设备、防盗防灾装置、安放监控等 。作为EPSON/爱普生晶振官网推荐代理商，江苏华体会真人备有现货并提供样品零售。销售价格请与江苏华体会真人官网在线客服咨询。如需技术支持，请向华体会真人技术部寻求选型支持。
| 产品型号 | 产品编码 | 标称频率 | 频率公差 | 购买 |
|---|---|---|---|---|
| SG5032CCN 40.000000MHz HJGA | X1G004471000800 | 40MHz | +/-50 ppm |  |
| SG5032CCN 33.330000MHz HJGA | X1G004471003100 | 33.33MHz | +/-50 ppm | |
| SG5032CCN 32.000000MHz HJGA | X1G004471000300 | 32MHz | +/-50 ppm | |
| SG5032CCN 29.491200MHz HJGA | X1G004471002300 | 29.4912MHz | +/-50 ppm | |
| SG5032CCN 27.000000MHz HJGA | X1G004471002200 | 27MHz | +/-50 ppm | |
| SG5032CCN 25.000000MHz HJGA | X1G004471000700 | 25MHz | +/-50 ppm | |
| SG5032CCN 24.576000MHz HJGA | X1G004471002100 | 24.5760MHz | +/-50 ppm | |
| SG5032CCN 24.000000MHz HJGA | X1G004471002000 | 24MHz | +/-50 ppm | |
| SG5032CCN 20.000000MHz HJGA | X1G004471000400 | 20MHz | +/-50 ppm | |
| SG5032CCN 18.700000MHz HJGA | X1G004471004500 | 18.70MHz | +/-50 ppm | |
| SG5032CCN 18.432000MHz HJGA | X1G004471001900 | 18.4320MHz | +/-50 ppm | |
| SG5032CCN 18.432000MHz HJGA | X1G004471001500 | 18.4320MHz | +/-50 ppm | |
| SG5032CCN 18.200000MHz HJGA | X1G004471004800 | 18.20MHz | +/-50 ppm | |
| SG5032CCN 17.700000MHz HJGA | X1G004471004700 | 17.70MHz | +/-50 ppm | |
| SG5032CCN 16.700000MHz HJGA | X1G004471003500 | 16.70MHz | +/-50 ppm | |
| SG5032CCN 16.000000MHz HJGA | X1G004471000600 | 16MHz | +/-50 ppm | |
| SG5032CCN 14.745600MHz HJGA | X1G004471001800 | 14.7456MHz | +/-50 ppm | |
| SG5032CCN 12.288000MHz HJGA | X1G004471001700 | 12.2880MHz | +/-50 ppm | |
| SG5032CCN 12.000000MHz HJGA | X1G004471003400 | 12MHz | +/-50 ppm | |
| SG5032CCN 11.289600MHz HJGA | X1G004471004100 | 11.2896MHz | +/-50 ppm | |
| SG5032CCN 11.059200MHz HJGA | X1G004471001600 | 11.0592MHz | +/-50 ppm | |
| SG5032CCN 10.700000MHz HJGA | X1G004471001300 | 10.70MHz | +/-50 ppm | |
| SG5032CCN 10.000000MHz HJGA | X1G004471001100 | 10MHz | +/-50 ppm | |
| SG5032CCN 8.000000MHz HJGA | X1G004471000500 | 8MHz | +/-50 ppm | |
| SG5032CCN 7.737280MHz HJGA | X1G004471004400 | 7.737280MHz | +/-50 ppm | |
| SG5032CCN 7.550000MHz HJGA | X1G004471005300 | 7.55MHz | +/-50 ppm | |
| SG5032CCN 7.372800MHz HJGA | X1G004471001000 | 7.3728MHz | +/-50 ppm | |
| SG5032CCN 7.175000MHz HJGA | X1G004471004300 | 7.1750MHz | +/-50 ppm | |
| SG5032CCN 6.950000MHz HJGA | X1G004471004600 | 6.95MHz | +/-50 ppm | |
| SG5032CCN 6.550000MHz HJGA | X1G004471004900 | 6.55MHz | +/-50 ppm | |
