32.768kHz有源晶振
| 型号 | 外部尺寸[ mm ] | 输出 | 频率范围 | 电源电压[ V ] | 温偏@工作温度[ ppm /℃] | 规格书 | 样品购买 |
|---|---|---|---|---|---|---|---|
 TG-3541CE (TCXO) |
3.2x2.5 | CMOS | 32.768kHz | 1.5~5.5 | XA: ±3.4 / -40~+85 XB: ±5.0 / -40~+85 XA / XB: ±8.0 / +85~+105 |
 |
TG-3541CE |
TG-3541CEA (TCXO) (AEC-Q100) |
3.2x2.5 | |
Contact us | ||||
| SG-3030CM | 3.2x1.5 | 5 ±23 / @ +25 工作温度：-40~+85 |
|
SG-3030CM | |||
| SG-3030LC | 3.6x2.8 | 5 ±23 / @ +25 工作温度：-20~+70 |
|
SG-3030LC | |||
| SG-3030JF | 7.1x5.1 | |
SG-3030JF | ||||
| SG-3030JC | 10.5x5.8 | |
SG-3030JC | ||||
| SG-3040LC | 3.6x2.8 | 0.9~3.6 | |
SG-3040LC | |||
| SG-3040JC | 10.5x5.8 | |
SG-3040JC |
MHz晶体振荡器
| 型号 | 外部尺寸[ mm ] | 输出 | 频率范围[ MHz ] | 电源电压[ V ] | 规格书 | 购买样品 |
|---|---|---|---|---|---|---|
| SG2016CAN | 2.0 x 1.6 | CMOS | 1.2~75 | 1.6~3.6 | |
SG2016CAN |
| SG2016CAA (汽车级) |
2.0 x 1.6 | 1.2~75 | |
Contact us | ||
| SG-210STF | 2.5 x 2.0 | 1~75 | |
SG-210STF | ||
| SG-210SEBA (汽车级) SG-210SDBA (汽车级) SG-210SCBA (汽车级) |
2.5 x 2.0 | 2~60 | 1.8 2.5 3.3 |
|
Contact us | |
| SG-210SCH | 2.5 x 2.0 | 80~170 | |
SG-210SCH | ||
| SG-310SCN | 3.2 x 2.5 | 2~48 (S*F) 3~80 (S*N) |
|
SG-310SCN | ||
| SG5032CCN | 5.0 x 3.2 | 1~75 (CAN) 80~170 (CBN) 2.5~50 (CCN) |
1.6~3.63 (CAN@CBN) 4.5~5.5(CCN) |
|
SG5032CCN | |
| SG7050CCN | 7.0 x 5.0 | |
SG7050CCN | |||
| SG3225VEN | 3.2 x 2.5 | LVDS | 25~200 | 2.5 3.3 |
|
SG3225VEN |
| SG7050VEN | 7.0 x 5.0 | |
SG7050VEN | |||
| SG3225EEN | 3.2 x 2.5 | LV-PECL | |
SG3225EEN | ||
| SG7050EEN | 7.0 x 5.0 | |
SG7050EEN | |||
| SG7050EBN | 7.0 x 5.0 | 100~175 | |
SG7050EBN | ||
| SG3225EAN | 3.2 x 2.5 | 73.5~700 | |
SG3225EAN | ||
| SG5032EAN | 5.0 x 3.2 | |
SG5032EAN | |||
| SG7050EAN | 7.0 x 5.0 | |
SG7050EAN | |||
| SG3225VAN | 3.2 x 2.5 | LVDS(VAN) | |
SG3225VAN | ||
| SG5032VAN | 5.0 x 3.2 | |
SG5032VAN | |||
| SG7050VAN | 7.0 x 5.0 | |
SG7050VAN | |||
| SG3225HBN | 3.2 x 2.5 | HCSL | 100~325 | 3.3 | |
SG3225HBN |
| SG-210SCB | 2.5 x 2.0 | CMOS | 2~32 (SGB) 2~60 |
1.5 1.8 2.5 3.3 |
|
SG-210SCB |
| SG-210SCD | 2.5 x 2.0 | 50~80 | 1.8 2.5 3.3 |
|
SG-210SCD | |
| SG-211SCE | 2.5 x 2.0 | 2.375~60 | 1.8 2.5 3.3 |
|
SG-211SCE | |
| HG-2150CA | 7.0 x 5.0 | 1.000~60.000 | 3.3 5.0 |
|
HG-2150CA | |
| SG-636SCG | 10.5 x 5.8 | 2.21675~33 | 3.0 3.3 5.0 |
|
SG-636SCG | |
| SG-615PCN | 14.0 x 9.8 | 1.5~66.667 | 3.0 3.3 |
|
SG-615PCN | |
| SG-531SCG | 13.7 x 6.6 (Dip half) | 1.5~26 | 3.0 3.3 |
|
SG-531SCG | |
| SG-636PDE | 10.5 x 5.8 | CMOS TTL | 2.21675~41 | 2.5 3.3 5.0 |
|
SG-636PDE |
| SG-636SCW | 10.5 x 5.8 | 32.001~135 | 3.3 5.0 |
|
SG-636SCW | |
| SG-615PTJ | 14.0 x 9.8 | 1.025~66.667 | 5.0 | |
SG-615PTJ | |
| SG-615SCW | 14.0 x 9.8 | 26.001~135 | 3.3 5.0 |
|
SG-615SCW | |
| SG-531PTJ | 13.7 x 6.6 (Dip half) | 1.025~66.667 | 5.0 | |
SG-531PTJ | |
| SG-531SCW | 13.7 x 6.6 (Dip half) | 26.001~135 | 3.3 5.0 |
|
SG-531SCW | |
| SG-51PTJ | 19.8 x 6.36 (Dip full) | 1.025~66.667 | 5.0 | |
SG-51PTJ |
